Applications
◆Track Private cars/Vehicle rental /Fleet management/ Equipment outside etc
◆Track container /cargo
Product Features
GPS+LBS+WIFI+BD+GLONASS LOCATION
Supports GPS&LBS+WIFI&BD&GLONASS.the users are able to use it outside and indoor globally.
VIBRATION ALERT
Build-in sensitive vibration sensor even if a slight vibration for 3second the device will send alarm to owner.
GEO-FENCE
Geo-fence will help you make safe area for your car/families .if carrier is out of safe area the device will send alarm to owner.
WATERPROOF IP66
Super waterproof makes the device can be used in rainy . Never worry about that it is broken when it is rainy.
HISTORICAL ROUTES
The server can store the data for half year so you can check the historical routes in APP&Web platform at any time.
MOVE ALERT
As long as the car is driven far from the sidtace which was set the device will send alarm to the owner via SMS&APP.
OVER SPEED ALERT
Build-in 3G-sensor ,Once the driver is beyong the safe speed that device will send alarm to the user.
BATTERY STANDBY LIFE
15600mAh rechargeable battery make sure device can be work up to 60 days.
Product specs
<td width="342" valign="center" colspan="1" style="padding: 0px 7px; border-left: none; border-right-width: 1px; border-right-color:
The name of the feature | Y | N | Description of the project's functionality | |||
Electrical characteristics | Power supply mode | ● | Battery-powered | |||
Operating voltage range | ● | DC 3.4V - 4.5V | ||||
Operating current | ● | 4V/ average 68mA | ||||
Sleep current | ● | 4V/ average 200uA | ||||
Built-in battery capacity | ● | 15600mAh (3.7V 18650*6P) | ||||
solar panel | open-circuit voltage | ● | 6V | |||
Operating voltage | ● | 5V (±0.3V) | ||||
short-circuit current (SCC) | ● | 440MA (±8%) | ||||
maximum current | ● | 400MA | ||||
Cell efficiency | ● | 23.5% | ||||
Environmental characteristics | Operating temperature range | ● | -20℃ - 60℃ | |||
Storage temperature range | ● | -30℃ - 80℃ | ||||
Operating humidity range | ● | 10%-85% RH non-condensing | ||||
Communication characteristics | SIM card | ● | ||||
Communication frequency bands | ● | LTE/4G | LTE-FDD:B1/B2/B3/B4/B5/B7/B8/B12/B13/ B18/B19/B20/B25/B26/B28/B66/ LTE-TDD :B34/B38/B39/B40/B41 GSM/GPRS/EDGE | |||
GSM/2G | 850/900/1800/1900MHz | |||||
Communication antennas | ● | Built-in antenna | ||||
Antenna specifications | ● | FPC antenna | ||||
Iridium Star | 频率 | ● | 1616 ～ 1626.5 MHz | |||
Maximum Mobile Message Size | ● | 340 per byte | ||||
Maximum Mobile Reception Information | ● | 270 per byte | ||||
Duplex mode | ● | TDD(Time-domain duplexing) | ||||
Antenna | ● | Size of the built-in ceramic active antenna：25*25*4 | ||||
GPS/BD positioning features | Locate the module brand/chip model | ● | Beidou + GPS | |||
Targeting method | ● | An average of 32 seconds | ||||
Cold start time | ● | An average of 1 second | ||||
Hot start time | ● | -162 dBm | ||||
Tracking sensitivity | ● | -148 dBm | ||||
Locate the antenna | ● | Built-in antenna | ||||
Antenna specifications | ● | 25mm * 25mm * 4mm | ||||
GPS bands | ● | L1: 1575.42±1.023MHz | ||||
Beidou frequency band | ● | B1: 1561.098±2.046MHz | ||||
Number of satellite channels | ● | 32 | ||||
Positioning accuracy | ● | <10m（1σ No previous NEXT：GT08
| ||||
