Applications
◆Track Pet/Animal/Dogs/ Cats
Product Features
GPS+LBS+WIFI+BD+GLONASS LOCATION
Supports GPS&LBS+WIFI&BD&GLONASS.the users are able to use it outside and indoor globally.
VIBRATION ALERT
Build-in sensitive vibration sensor even if a slight vibration for 3second the device will send alarm to owner.
GEO-FENCE
Geo-fence will help you make safe area for your car/families .if carrier is out of safe area the device will send alarm to owner.
WATERPROOF IP67
Super waterproof makes the device can be used in rainy . Never worry about that it is broken when it is rainy.
HISTORICAL ROUTES
The server can store the data for half year so you can check the historical routes in APP&Web platform at any time.
BATTERY STANDBY LIFE
700mAh rechargeable battery make sure device can be work up to 7 days.
Product specs
Content | Specs. |
Dim. | 40mm x 34mm x 14mm |
Weight | 68g |
Band&Network | FDD-LTE:B1 B2 B3 B4 B5 B7 B8 B12(17) B20 B28 TDD-LTE: B38 B39 B40 B41 WCDMA:B1 B2 B5 B8 GSM:850/900/1800/1900 |
GPS chip | SC9820E |
| Electrostatic Protection | Touch +/-7KV Not Touch +/-14KV |
Number of channels | 66 Channels |
GPS sensitivity | -165dBm |
GPS accuracy | 10m |
Time To First Fix | Cold status 35-80 s Warm status 35s Hot status 1s |
| Wall charge | 110－220V input 5V output |
| Battery | Rechargeable 3.7V 700mAh Li-ion battery |
Standby | 7 days |
| Storage Temp. | -40°C to +85°C |
| Operation Temp. | -20°C to +55°C |
| Humidity | 5%--95% non-condensing |
